UPS ARES AR-MP1KSRT 1KVA (1000W) ONLINE

AR-MP1KSRT
AR-MP1KSRT

UPS ARES AR-MP1KSRT 1KVA (1000W) ONLINE

  • Power: 1kVA/1kW.
  • Standard sine wave.
  • Technology: Online
  • 24 months warranty
  • Output power factor up to 1.
  • Switching time: 0ms
  • Backup time: 16 minutes 50% load
  • Output power connection: 3 Universal sockets
  • Battery: 3x12V/9AH
  • Dimensions (RxDxC): 440 x 460 x 86.5
SKU: E-AR-MP1KSRT Category: Tags: , , , , ,
  • Description
  • Tải tài liệu
  • Thông số

Description

UPS ARES AR-MP1KSRT 1KVA (1000W) ONLINE

  • Rack/Tower Switch Design Online dual conversion with full digital control
  • Wide input voltage range: 110 ~ 300Vac
  • Input Power Factor 0.99 with PFC
  • Selectable output voltage: 208/220/230/240Vac
  • Smart charger design to optimize battery performance
  • The maximum charging current can be extended to 12A (H series)
  • Emergency power off (EPO) function
  • Works in ECO mode to save energy
  • Compatible with generators
  • Hot-swappable battery design
  • Cold start
  • Smart fan speed adjustment
  • Load segment can be set (Optional)
  • Multi-function LCD screen
  • Multiple communication interfaces: RS232 (optional USB / EPO / Relay card / SNMP card)
  • Multiple protection functions: short circuit, overcharge, over temperature, overload and battery overload, output low voltage and fan fault

bộ lưu điện ares, bộ lưu điện 1kva online, bộ lưu điện 2kva online, bộ lưu điện 3kva online, bộ lưu điện 6kva online, bộ lưu điện 10kva online, bộ lưu điện 1 pha, bộ lưu điện 3 pha, ups lưu điện, bộ lưu điện offline, bộ lưu điện

Catalogue ARES AR-MP RT (1kVA_3kVA)

ARES MP1-3KVA (S#H) Rack UPS User manual



Technical Specification

MODEL AR-MP1KHRT AR-MP1KSRT AR-MP2KHRT AR-MP2KSRT AR-MP3KHRT AR-MP3KSRT
Capacity 1000VA/ 900W 2000VA/ 1800W 3000VA/ 2700W
INPUT
Nominal voltage 208/220/230/240Vac
Input voltage range 110~300Vac (176~280Vac @ 100% load)
Frequency range 40~70Hz  (50/60Hz Auto-Sensing)
Power factor ≥0.99
OUTPUT
Output voltage 208/220/230/240Vac
Power factor 0.9
Voltage regulation ±1%
Output frequency Line Mode 46~54Hz or 56~64Hz
Bat. Mode (50/60±0.1%)Hz
Crest factor 3:01
Harmonic distortion (THDv) ≤3% Linear load
≤5% Non linear load
Transfer time AC mode to Bat.Mode 0ms
Inverter to Bypass 4ms (Typical)
Output waveform Pure Sinewave
EFFICIENCY
AC mode 89% 91% 92%
Battery mode 85% 87% 88%
BATTERY
Battery number 2 3 2 3 4 6 4 6 6 8 6
Capacity (Standard unit) 9Ah/12V
Typical recharging time 4 hours (to 90% of full capacity)
Charging voltage 27.4Vdc±1% 41.1Vdc±1% 27.4Vdc±1% 41.1Vdc±1% 54.8Vdc±1% 82.2Vdc±1% 54.8Vdc±1% 82.2Vdc±1% 82.2Vdc±1% 109.6Vdc±1% 82.2Vdc±1%
Charging current (Max) 6A/12A 1A 6A/12A 1A 6A/12A 1A
INDICATORS
LED display Line mode,Bat.mode,ECO mode,Bypass mode,Battery low voltage,Overload & UPS fault
LCD display Input voltage,Input frequency,Output voltage,Output frequency,Load percentage,
Battery voltage,Inner temperature& Remaining battery backup time
ALARM
Battery mode Beeping every 4 seconds
Battery low Beeping every second
Overload Beeping twice every second
Fault Continously beeping
PHYSICAL
Dimension W x D×H (mm) 440 x 325x 86.5 440 x 460 x 86.5 440 x 600 x 86.5 440 x 460 x 86.5 440 x 600 x 86.5
Net weight (kg) 5.6 11.3 14 10.5 19.5 25 11 26
ENVIRONMENT
Operating temperature 0℃~40℃
Storage temperature -25℃~55℃
Humidity range 20~95%RH @ 0~40℃ (Non condensing)
Altitude <1500m,derating required when>1500m
Noise level <50db at 1 Meter
STANDARDS
Safety IEC/EN62040-1,IEC/EN62477-1
EMC IEC/EN62040-2,IEC61000-4-2,IEC61000-4-3,IEC61000-4-4,IEC61000-4-5,IEC61000-4-6,IEC61000-4-8
