BỘ LƯU ĐIỆN UPS AR630H
- Power: 3000VA/2400W
- Technology: Line interactive, Automatic voltage stabilizer (AVR)
- Input voltage: 165Vac – 280Vac
- Output voltage: 220V
- Frequency: 50/60Hz (automatic reception)
- Waveform: Standard sine wave
- Connect PC via USB port + Smart Slot
- Monitoring software: free
- Port surge protection, data line lightning protection
- Socket: 6 Universal socket
- Battery voltage: 48VDC
- Dimensions: R190*D467*C335.5 (mm)
- Description
- Thông số kỹ thuật
- Tải tài liệu
Description
The AR630H UPS helps to increase the backup time to many hours
To increase the backup time, we have 2 options:
- Buy a UPS with a capacity many times larger than the actual load capacity to save electricity for a long time => high cost.
- Buy a UPS with a capacity that meets reality and invest in an external battery pack, with the UPS manufacturer’s own battery or a third party => lower cost.
Model AR630H with external battery to increase battery backup time. This solution is more and more popular due to the flexibility in investing in replacing battery packs that can extend the backup time by connecting batteries in parallel to increase capacity => saving costs. investment fees. With a power factor of 0.8, UPS capacity increases by 30% compared to similar UPSs on the market.
In addition, Line-interactive models have AVR (auto voltage regulation) that automatically adjusts voltage allowing the UPS to be suitable for use in locations with abnormal surges/falls in current; at the same time, it allows to turn on and off the UPS remotely via software, notify the problem via email or message when using the SNMP card.
Features AR630H
- Line Interactive technology. Standard sine waveform.
- Automatic voltage regulation (AVR) function.
- Power factor 0.8.
- Adjust the charging current and battery voltage to turn off the machine.
- Set power saving mode when no load.
- Smart alarm system.
- Automatically start when mains power is available.
- Smart battery management function.
- Short circuit, overload protection.
- Automatically charge the battery even when the UPS is off.
Application UPS AR630H:
- For computers, printers, fax machines.
- Network equipment.
- Elevator control cabinet, weighing station.
- Telephone exchange, security camera system – recorder.
- Fire alarm system – alarm.
- Automatic doors, rolling doors, magnetic doors.
Specifications AR630H
- Power: 3000VA-2400W. Standard sine wave.
- Technology: Line Interactive.
- Input source: 165~280Vac 50~60Hz (auto)
- Output: 220V ± 8% 50/60Hz ± 1% (auto)
- Power factor: PF 0.8.
- Communication port: USB, RS232, SNMP Slot.
- Guard port: RJ45.
- Free software that connects via USB port to monitor UPS activity
- Set shutdown time, automatically back up data before shutting down the system
- Output power connection: 6 universal sockets
- Battery: 48VDC. Maintenance-free air-tight dry batteries.
- Alarm mode: utility failure, low battery, overload, UPS failure
- Comprehensive protection: short circuit protection, battery overcharge/over discharge, overload, over temperature
- Eco Mode (ECO Mode): Yes.
- No – load Shutdown : Yes.
- Battery backup time: Depends on the device.
- Switching time: 3 - 5 ms.
- Case: metal. Color: matte black.
- Dimensions (W*D*H): 190*467*335.5.
- Weight (Kg): 28.
